Electromechanical operator for swing doors

Κατόπιν παραγγελίας
1,456.00€

 Electromechanical operator for swing doors

 A user friendly operator for a number of applications.  ISO3 is the ideal choice for all applications that require:

  • Power and management for high traffic
  • Safety of people and buildings in accordance with applicable regulations
  • Flexible and soft opening for the elderly and handicapped
  • Comfortable and clean for access in sensitive areas
  • Standards: EC-EN 61000 6-3, EN 61000 6-2, EN 16005/IS, UL325, EN 60335, EN 13849-1, NFS 61937-1, NFS 61937-2
Dimensions :102 x 136 x 650 mm
Weight :Push: 250 kg Pull: 160 kg (width 0.8 m)
Max opening angle :Push: 120 Pull: 950
Min/max leaf width :720-3000 mm depending of door type and leaves
Pulling door- Closer power :Push: 160 kg Pull: 100 kg
Adjustable speeds :Opening: 10 to 60/s Closing; 10 to 50 /s
Hold opening time :0 to 25 s 3 hold times: Complete opening, Master-slave partial opening, Priority opening
Sound level :55 dBA measured from a distance of 25 cm
